Product Description

12-3727E-EAB Sargent 30 Series Reversible Fire Rated Vertical Rod Exit Device in Brass Finish

The Sargent 12-3727E-EAB exit device are used for the single and double door application. The 3727 Multi-function Surface vertical rod exit device is the perfect stocking device. The 3727 series exit device are certified to the ANSI/BHMA Standard 156.3, Grade 1.

Features and Benefits:

• Brass finish
• Door thickness: 1-3/4" (44) thick standard
• Handing: Reversible
• Steel endcaps and covers
• Fire rated exit device
• Rail assembly: Roll formed steel
• Latchbolt: Brass
• Strike: 646 Top strike, 655 bottom strike
• Mounting: Furnished standard with wood and machine screws
• Rail sizes for doors: 24' through 32" (61cm through 81cm)
• Chassis mounted unit construction assures easy installation and maintenance
