Product Description

8800-M-48-US3 Adams Rite Life-Safety Narrow Stile Rim Exit Device in Bright Brass Finish

The 8800-M-48-US3 series Exit Device has patented "Starwheel" bolt interlocks door to frame with strong and durable construction for a high level of security. It is clean with unobtrusive design for clean sight lines and is very easy to install.

Benefits and Features:

• Bright Brass pushbar finish
• Pushbar length: 48 inches
• Life safety
• Pushbar made of extruded aluminum, clad or anodized material
• Door Thickness: Suits 1-3/4" standard up to 2-1/4"
• Stile Width: Minimum 2" Stile
• Projection: 2-5/8" when fully projected, 1-5/8" when dogged
• Non-handed operation and lever entry trim is field reversible
• Patented "Starwheel" bolt interlocks door to frame
• Strong and durable construction for a high level of security
• Easy to install with clean and unobtrusive design for clean sight lines
• Grade 1 strength
• Included strike is made of hardened steel
• Standard self-tapping screws fastener
• Standard dogging with hex key
• Single switch monitoring feature
• Starwheel Bolt:
  • when door closes, the interlocking noseguard and starwheel bolt close around the strike, the deadlocking slide springs over and thus locking the starwheel bolt to the strike
  • when pushbar is depressed, the deadlocking slide moves back, allowing the door to unlock from the strike. This unique interlock provides solid security and prevents jamb spreading
• 5 year limited manufacturer's warranty is included
