Product Description

9KW37DEL14CS3625RQELM Best 9KW Series Fail Safe Electromechanical Heavy Duty Cylindrical Lock with Curved w/ Return Style in Bright Chrome Finish

The Best 9KW37DEL14CS3625RQELM series is one of the toughest electrified heavy-duty cylindrical locks on the market with the proven Grade 1 security. The 9KW series is provide a way to lock and unlock the door from a remote location for safety, security, or convenience through an individual switch, switch lock, relay, access control system, or other automatic control system. The Best 9KW series are listed by the BHMA for A156.2, Series 4000, Grade 1.

DEL-fail safe: Latch operated by rotating the inside lever and rotating the outside lever - only when power is off. Turning the key in the outside lever. Outside lever locked by applying power to the solenoid; remains locked while power is on. Inside lever can not be locked.

Features and Benefits:

• Bright Chrome finish
• Backset: 2-3/4" standard
• Handing: Non Handed
• RQE: Request to exit
• Single keyed function - fail safe
• 24 volts AC or DC - 0.18 amps standard
• Core is not included
• 7-pin housing accepts all BEST cores
• Door thickness: Available for 1-3/4" to 2-1/4" doors only
• Latch: Solid brass 9/16" throw. Front 2-1/4" x 1-1/8" beveled
• Strike: S3 - ANSI A115.2 for 1-3/4" doors (4-7/8" x 1-1/4" with curved lip)
• Projection on door - Approx 2-3/4" when mounted on 1-3/4" door.
• Lever style: 14 - Curved with return
• Rose style: C - 3" convex
• Deadlocking latchbolt standard
• Fasteners: All mounting screws are concealed. All machine screws (AMS) standard.

*Note: It includes a lost motion design allowing the lever to move 45°-60° without engaging the retractor assembly.
