Product Description

B563P-613 Schlage Grade 2 Classroom Deadbolt Lock with C Keyway in Oil Rubbed Bronze Finish

The Schlage B563P-613 B500 series deadbolt is the hardest and most adaptable deadbolt on the market. The B500 Series deadbolt was designed by locksmiths for locksmiths and accommodates every Schlage cylinder on the market. It fits practically every door you service, improves lock strength on the jamb side of the door, and will change forever the way you look at deadbolts.

Features and Benefits:

• Oil Rubbed Bronze finish
• One-way deadbolt lock
• Door Thickness: 1-3/8 In. - 1-7/8 In.
• Std. Latch Backset Dim: Adjustable 2-3/8 In. and 2-3/4 In.
• Lock Face Size: 2-1/4 In. x 1 In.
• Bolt Projection: 1 In.
• Std. Strike Number: 10-094
• Std. Strike Type: Flat
• Std. Strike Height: 2-3/4 In.
• Std. Strike Width: 1-1/8 In.
• Keyway: C standard
• Strike: Square Corner (Standard)
• Keyed Outside/Classroom Thumbturn Inside
• ANSI A156.5, 2001 Grade 2
• Available UL Listed for three-hour fire door
• Quick, easy installation
• Adjustable backset locks into place
• Anti-pry shield protects latch from attacks
• Metal dust box provides deep anchoring and added strength
• Primary or auxiliary locking for commercial buildings
• High security locking for residential buildings
• Can be suited with virtually all Schlage levers and knobs
