Product Description
CL3372-NZD-613-LC Corbin CL3300 Series Less Cylinder Extra Heavy Duty Public Toilet Cylindrical Locksets with Newport Lever in Oil Rubbed Bronze Finish
The Corbin CL3372-NZD-613-LC Extra heavy-duty cylindrical lockset is a Grade 1 lever lockset manufactured with the highest quality materials to ensure strength, durability and quiet operation. The CL3300 Series supplements any high-use commercial, industrial and institutional application. The Corbin Russwin CL3300 series engineered to meet today's increased security needs, offers several advantages. The CL3300 series are certified to the ANSI/BHMA A156.2 Series 4000 Grade 1.
Public toilet: Deadlocking latchbolt by lever either side, except when key inside locks outside lever. Key outside retracts latchbolt. Key inside unlocks outside lever. Inside lever always free.
Features and Benefits:
- Oil Rubbed Bronze finish
- Extra heavy duty cylindrical lever locksets
- Double cylinder lockset
- Handing: Non-handed
- No cylinders are included with this lock
- Newport lever design with D rose (NZD)
- Door thickness: 1-3/4" (44mm) - 2" (51mm) standard
- Backset: 2-3/4" (70mm) standard
- Lock chassis: Steel, zinc dichromated for corrosion resistance.
- Latchbolt: Stainless Steel, 1/2" (13mm) throw.
- Front: Wrought brass, bronze, or stainless steel, 2-1/4" (57mm) x 1-1/8" (29mm).
- Strike: ANSI curved lip standard, 4-7/8" (124mm) x 1-1/4" (32mm) x 1-1/4" (32mm) lip to center
