Product Description

MA321-QG-625 Falcon Mortise Locks MA Series Privacy with QG Lever in Bright Chrome Finish

The Falcon MA321-QG-625 Privacy function mortise lock is designed for office buildings, universities, healthcare facilities, and multi-family applications and delivers high performance at an affordable cost. Falcon is one of the toughest, most dependable locks. The MA Series provides security and is built to stand up to constant use without fail and lock makes retrofitting easy with its ability to be re-handed in the field without opening the mortise case. The MA series are certified to BHMA ANSI A156.13, Series 1000, Grade 1 operational along with UL 3 hour ratings.

Privacy Lock: Latch bolt operated by lever from either side except when outside lever is locked by inside T-turn. Operating inside lever, closing door or operating outside emergency release unlocks outside lever. Inside lever is always free for immediate egress.

Features and Benefits:

• Bright Chrome finish
• Door range: 1-3/4" - 1-7/8" standard
• Strike: 1-1/4" x 4-7/8", ANSI, Square corner, with dust box
• Latch bolt: 2 piece stainless steel anti-friction bolt 3/4" projection.
• Backset: 2-3/4" backset
• Hubs: Hardened steel
• Door thickness: Standard accommodates thickness of 1-3/8" to 2-1/2"
• ANSI: F22
• QG(Quantum-Gala) lever trim
• Non-keyed functions
• Handed: Right hand is standard; left hand optional. Reversible in the field.
