Product Description

MA431P-DG-625 Falcon Mortise Locks MA Series Classroom Security with deadbolt with DG Lever in Bright Chrome Finish

The Falcon MA431P-DG-625 Classroom Security function mortise lock is designed for office buildings, universities, healthcare facilities, and multi-family applications and delivers high performance at an affordable cost. Falcon is one of the toughest, most dependable locks. The MA Series provides security and is built to stand up to constant use without fail and lock makes retrofitting easy with its ability to be re-handed in the field without opening the mortise case. The MA series are certified to BHMA ANSI A156.13, Series 1000, Grade 1 operational along with UL 3 hour ratings.

Classroom Security Lock with Deadbolt: Latch bolt operated by lever from either side except when outside lever is locked from inside or outside by key. Dead bolt retracted by key from inside or outside. Operating inside lever retracts both bolts and unlocks outside. Latch bolt dead locked when dead bolt is thrown. Inside lever is always free for immediate egress.

Features and Benefits:

• Bright Chrome finish
• Door range: 1-3/4" - 1-7/8" standard
• Strike: 1-1/4" x 4-7/8", ANSI, Square corner, with dust box
• Standard keys are included
• Latch bolt: 2 piece stainless steel anti-friction bolt 3/4" projection.
• Backset: 2-3/4" backset
• Hubs: Hardened steel
• Door thickness: Standard accommodates thickness of 1-3/8" to 2-1/2"
• ANSI: F34
• DG(Dane-Gala) lever trim
• Double cylinder
• Handed: Right hand is standard; left hand optional. Reversible in the field.
• Cylinders: 6 Pin cylinder to 5 chambers standard
