Product Description

T381PD-Q-626 Falcon T Series Cylindrical Exit Security Lock with Quantum Lever Style in Satin Chrome Finish

The Falcon T381PD-Q-626 Extra heavy duty cylindrical lock is used for offices, schools, hospitals, apartments, hotels, motels and other public building applications. The Falcon T series lock is the most versatile lockset and accept any manufacturer's cylinder, and the cylinder can easily be removed for quick, easy re-keying. This versatile lock is well suited to either new construction or retrofit use in buildings as varied as multi-family, retail, institutional and government/military. This T series locks are certified to ANSI/BHMA A156.2, Series 4000,Grade 1, UL Listed for 3-hour fire door.

Classroom security lock - Deadlocking latch bolt by levers from either side except when outside lever is locked by key from inside. Outside key only retracts latch. Outside lever is locked and unlocked only by inside key.

Features and Benefits:

• Satin Chrome finish
• Door range: 1-3/4" - 2-1/8" standard
• Handing: Non-handed
• Double cylinder
• ANSI: F88-1
• Standard keys are included
• Q (Quantum) lever trim
• Keyway: G keyway standard
• Backset: 2-3/4" backset standard
• Cylinders: 5 pinned cylinder
• Latch: 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1/2" throw
• Strike: 4-7?8" x 1-1?4" ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard
